Bilateral Congenital Diaphragmatic Hernia
Department of Pediatric surgery and Pediatrics1, Maulana Azad Medical College, Delhi 110002.
Abstract
Bilateral congenital diaphragmatic hernia (CDH) is a rare birth defect, with a poor prognosis. We describe a case of bilateral CDH discovered while repairing the right sided CDH. Diaphragmatic defect was repaired and a silo was applied on the abdominal wound to avoid abdominal compartment syndrome. The patient however died postoperatively due to severe pulmonary hypertension.
Received: 2012 May 24; Accepted: 2012 June 12
Copyright
Copyright © 2012 Dhua et al
Keywords: Bilateral congenital diaphragmatic hernia, Pulmonary hypertension, Silo.INTRODUCTION
Congenital diaphragmatic hernia occurs in every 2000-3000 live births [1]. Bilateral CDH is extremely rare, constituting less than 1% of all CDH cases [2]. Most of them die in utero while less than 35% survive [3,4]. The management of bilateral CDH is a challenge for pediatric surgeons and the neonatologists. We report a case of bilateral CDH with sac on both sides.
CASE REPORT
A male baby was born to a 30-year-old second gravida by normal vaginal delivery, in a private hospital. The baby had birth asphyxia and resuscitated with bag and mask ventilation. APGAR scores were 6 and 7 at 3 and 5 minutes, respectively. Patient was kept in the intensive care unit under oxygen hood and feeds were started.
He was referred to our hospital on day 6 with persistent respiratory distress. On admission his respiratory rate was 70/min, SpO2 was 87% with oxygen hood. The abdomen was soft and not distended. Air entry on both sides was reduced, more so on the right side. Liver dullness was noted abnormally high in the chest. A chest radiograph suggested right sided diaphragmatic eventration. Patient was intubated and ventilation started. A repeat radiograph showed elevated right hemi-diaphragm and shift of mediastinum to the left (Fig. 1A). Echocardiography revealed no cardiac abnormality.
After preoperative stabilization the baby was operated through a right subcostal incision. The liver was very large and difficult to manipulate, hence the incision was extended in a roof top fashion. Falciform ligament was divided to mobilize the liver. It was discovered that a large part of right lobe of liver was inside the right hemithorax. The intrathoracic portion of right liver was reduced into the abdomen by gentle manipulation. This revealed a well defined defect in the diaphragm with well formed anterior and posterior lips of the muscle of the diaphragm. The lung was visible through a transparent sac (Fig. 2A). Manipulation of the left lobe of liver revealed a diaphragmatic hernia on the left side as well. The content of left hernia was part of left lobe of liver, spleen and a small part of splenic flexure of colon. There was a sac covering the contents.
[Figure ID: F2]
The contents were reduced, sac excised and the defect closed with polypropylene sutures on both sides. Intercostal tubes were placed on both sides. After reducing liver and other contents, primary closure of the abdominal wall was not possible. Hence a silo was created using a polypropylene mesh sandwiched between two layers of Ioban TM (3M, Minnesota, USA). Postoperatively the baby was electively ventilated at rates of 50 per minute and FiO2 of 80%. The silo was further reduced by 1.5 cm after 24 hours. The patient, however, deteriorated and developed severe pulmonary hypertension. Alt-hough the lung showed reasonable expansion on a post operative chest radiograph (Fig. 1B), the child went into refractory shock and died 30 hours after surgery.
DISCUSSION
CDH occurring in the neonatal period is mostly of the Bochdalek type. The defect is usually unilateral and involves the left diaphragm in 75% of cases [5]. On the contrary, bilateral CDH is rare and usually fatal.
Antenatal diagnosis of CDH is relatively easy and the sonographic indicators of unilateral CDH are mediastinal shift, presence of intestine in thorax, small abdominal circumference and polyhydramnios [6]. Mediastinal shift is often the first abnormality observed. In our case the diagnosis was missed. Song and workers [7] in 2001 reported antenatal detection of bilateral CDH in a fetus and concluded that bilateral diaphragmatic hernia should be suspected when the degree of mediastinal shift is less than that anticipated for a unilateral hernia in presence of other features of CDH.
The first survivor of bilateral CDH in UK was reported in 1990 [8]. In 1987 Furuta et al [2] presented the 11th reported case of bilateral CDH. The patient expired in the postoperative period after repair of right CDH while the left side CDH was identified at autopsy. In our case there was no preoperative suggestion of left sided hernia. We discovered the contralateral CDH only at the time of operation when difficulty in reduction of liver was encountered. We favour an abdominal approach for all diaphragmatic hernias including the right CDH as the liver can be best handled and mobilized through the abdominal approach. In our case part of the right lobe had herniated through a defect in the diaphragm. The edge of the diaphragm caused an indentation in the liver. This produced an hour glass configuration with a large portion of liver inside thorax, a narrow neck and another large portion in the abdomen. Simply pushing it from above from a thoracic approach would have been quite difficult. Further the left sided pathology would have been completely missed. Also a silo can only be used with abdominal approach.
Kufeji and Crabbe in 1999 reported familial inheritance of bilateral CDH in two consecutive siblings with a similar kind of bilateral CDH [9]. Both the siblings in their report could not be diagnosed antenatally. The outcome of majority of these cases is poor. In 2003 Neville et al retrospectively reviewed cases of CDH treated in 83 different hospitals in USA. They found that in bilateral CDH mortality rate was 65% compared with 33% of patients with unilateral CDH [4]. In contrast, anecdotal reports of patients with good outcome have also been published in literature. Zaupa et al in 2007 reported a case of bilateral CDH with gastroschisis with a favorable outcome [10]. They hypothesized that a low intrathoracic pressure due to gastroschisis may have been responsible for good lung development and a good patient outcome. In our case although the preoperative stabilization was good, there was severe pulmonary hypertension that led to the mortal outcome. In conclusion, our case highlights the diagnostic difficulty that can occur in these rare cases.
Footnotes
Source of Support: Nil
Conflict of Interest: None declared
1. | Langham MR, Kays DW, Ledbetter DJ, Frentzen B, Sanford LL, Richards DS. Congenital diaphragmatic Hernia: Epidemiology and outcome. Clin Perinatol 1996 23: 671– 88. |
2. | Furuta Y, Nakamura Y, Miyamoto K. Bilateral congenital posterolateral diaphragmatic hernia. J Pediatr Surg 1987 22: 182– 3. |
3. | Jandus P, Savioz D, Purek L, Frey JG, Schnyder JM, Tschopp JM. Bochdalek hernia: a rare cause of dyspnea and abdominal pain in adults. Rev Med Suisse 2009 5: 1061– 4. |
4. | Neville HL, Jaksic T, Wilson JM, Lally PA, Hardin WD Jr, Hirschl RB, et al. Bilateral congenital diaphragmatic hernia. J Pediatr Surg 2003 38: 522– 4. |
5. | Tofts CD, Curry CJR, Basteson TF, Honore LH. A population based study of congenital diaphragmatic hernia. Teratology 1992 46: 555– 65. |
6. | Adzick NS, Harrison MR, Glick PL, Nakayama DK, Manning FK, deLorimier AA. Diaphragmatic hernia in the fetus: prenatal diagnosis and outcome in 94 cases. J Pediatr Surg 1985 20: 357– 61. |
7. | Song MS, Yoo SJ, Smallhorn JF, Mullen JB, Ryan G, Hornberger LK. Bilateral congenital diaphragmatic hernia: diagnostic clues at fetal sonography. Ultrasound Obstet Gynecol 2001 17: 255– 8. |
8. | Bruce J, Doig CM. Survival following repair of bilateral diaphragmatic hernia. J R Coll Surg Edin 1990 35: 389. |
9. | Kufeji DI, Crabbe DC. Familial bilateral congenital diaphragmatic hernia. Pediatr Surg Int 1999 15: 58– 60. |
10. | Zaupa P, Kleinlein B, Hollwarth ME. Bilateral congenital diaphragmatic hernia and gastroschisis in a newborn: can low intrathoracic pressure prevent the pulmonary hypoplasia?. Pediatr Surg Int 2007 23: 711– 3. |
